Table 3. AC power requirements
Parameter Specifications
Power supply 100–240 VAC 50/60 Hz
Typical current draw per platform
• 110VAC: 1.89A (16 core) 240VAC: 0.86 A (16 core)
• 110VAC: 1.5A (8 core ) 240VAC: 0.7A (8 core)
• 110VAC: 1.35A (4 core) 240VAC: 0.65A (4 core)
Maximum power capability
• 5-fan 16-core processor: 311W
• 4-fan 8-core processor: 230W
• 4-fan 4-core processor: 220W
Typical power consumption
• 5-fan 16-core processor: 206.5W
• 4-fan 8-core processor: 170W
• 4-fan 4-core processor: 160W
Table 4. Expansion card AC power requirements
Parameter Specifications
Maximum power consumption* 0.9 Watt rNDC Carrier
15 Watt WIFI
Typical power consumption* 0.37 Watt rNDC Carrier
7 Watt WIFI
rNDC power can be found in their respective datasheets.
*For the most current power consumption specifications, see the Installation Guide at www.Dell.com/support.
VEP4600 Expansion Card antennas
The following explains the best antenna position for maximum signal reception.
CAUTION:
The external antennas are certified for indoor use only.
CAUTION: The use of external signal amplifiers in-line with the transceiver antennas is strictly prohibited.
CAUTION: The product shall be installed in a location where the radiating antenna is kept 20 cm from nearby persons in
its normal operational condition to meet global regulatory RF exposure requirements.
CAUTION: Use only the antenna(s) which have been approved by the applicant. Non-approved antenna(s) may produce
unwanted spurious or excessive RF transmitting power which may lead to a violation of FCC/IC limits and is prohibited.
CAUTION: The certified Wi-Fi antennas provided with this product are dipole type with a maximum gain per the
following table.
Table 5. Antenna specifications
Antenna specifications
WIFI Antenna
Frequency 2400 - 2500 MHz 5150 - 5850 MHz
Gain 2 dBi 2.5 dBi
BLE Antenna
Frequency 2400 - 2500 MHz
Gain 2 dBi
14 Specifications
