50 Specifications
Dimensions (W x H x D) 11.26 x 3.54 x 7.56 inches (286 x 90 x 192 mm)
Environmental Operating temperature: 5
o
C - 35
o
C (41
o
F- 95
o
F)
Humidity: 80% maximum
Storage temperature: 0
o
C to 60
o
C (32
o
F to 140
o
F)
Humidity: 90% maximum
Shipping temperature: -20
o
C to 60
o
C
(-4
o
F to 140
o
F)
Humidity: 90% maximum
I/O Connectors Power: One AC power socket (3-pins - C14 inlet)
VGA input: Two 15-pins D-sub connectors (Blue),
VGA-A & VGA-B, for analog RGB/Component
input signals.
VGA output: One 15-pins D-sub connector (Black)
for VGA-A loop through.
S-Video input: One standard 4-pins min-DIN S-
Video connector for Y/C signal.
Composite video input: One Yellow RCA jack for
CVBS signal.
Analog Audio input: One 3.5mm stereo mini phone
jack (Green).
Fix audio output: One 3.5mm stereo mini phone
jack (Blue).
USB port: One USB slave for remote support.
Lamp Philips 185W user-replaceable lamp (up to 4000
hours in eco mode)
3.54"(90mm)
11.26"(286mm)
7.56"(192mm)
