6 About Your Dell Projector
Projector Connections
CAUTION: Before you begin any of the procedures in this section,
follow the Safety Instructions as described on page 7.
1 Mini USB (mini type B)
connector for firmware upgrade
8 + 5V/1.8A DC out connector
2 RJ-45 connector 9 RS232 connector
3 VGA input connector 10 Audio input connector
4 VGA output (monitor loop
through) connector
11 Audio output connector
5 Composite Video connector 12 Security cable slot
6 HDMI-1 connector 13 Power cord connector
7 HDMI-2 connector
1 2 3 6 7 8 9 104 5
12 11
13
