Connecting Your Projector
CAUTION: Before you begin any of the procedures in this section, follow the
Safety Instructions as described on page 7.
1 USB remote connector 9 Audio-A input connector
2 HDMI connector 10 Microphone connector
3 VGA-A output
(monitor loop-through)
11 RS232 connector
4 VGA-A input (D-sub) connector 12 RJ45 connector
5 VGA-B input (D-sub) connector 13 Security cable slot
6 S-video connector 14 Audio output connector
7 Composite video connector 15 Audio-B left-channel input
connector
8 Audio-B right-channel input
connector
16 Power cord connector
3 4 5 6 7
8
15 14
1 2
13
9 10 11 12
16
