Dell 1850 - Page 15

Adjusting Projector Image 15
Adjusting Image Shape
Projection
Distance
(m)
[A]
Min Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal
(inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.2 33.46"/84.99 cm 74 42 48 6
3 84"/213.36 cm 185 104 121 17
5 139"/353.06 cm 309 174 201 27
7 195"/495.3 cm 432 243 282 39
9 251"/637.54 cm 556 313 363 50
10 279"/708.66 cm 617 347 401 54
Projection
Distance
(m)
[A]
Max Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal (inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.2 37"/93.98 cm 81 46 53 7
3 92"/233.68 cm 203 114 132 18
5 153"/388.62 cm 338 190 220 30
7 214"/543.56 cm 473 266 309 43
9 275"/698.5 cm 608 343 397 54
10 305"/774.7 cm 676 380 441 61
* This graph is for user reference only.
* Offset Ratio: 116±5%
