6 About Your Dell Projector
Projector Connections
CAUTION: Before you begin any of the procedures in this section,
follow the Safety Instructions as described on page 7.
1 + 5V/1A DC out connector 6 HDMI connector
2 VGA output (monitor loop
through) connector
7 Audio input connector
3 VGA input (D-sub) connector 8 Composite Video connector
4 Power cord connector 9 Audio output connector
5 Mini USB (mini type B)
connector for remote mouse
and firmware upgrade
