Dell 2005FPW - UltraSharp - 20.1" LCD Monitor User Manual

DATE: 2004. 10. 05.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R521 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R522 0RJ1052D477 10.5K OHM 1/10 W 1% 1608 R/T
R528 0RJ1502D677 15K OHM 1/10 W 5% 1608 R/TP
R529 0RJ1502D677 15K OHM 1/10 W 5% 1608 R/TP
R530 0RJ1502D677 15K OHM 1/10 W 5% 1608 R/TP
R531 0RJ1502D677 15K OHM 1/10 W 5% 1608 R/TP
R532 0RH1004D622 1.0M 1/10W 5 D.R/TP
R533 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R575 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R579 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R581 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R583 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R585 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R586 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R588 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R592 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R593 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R595 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R597 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R601 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R604 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R606 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R607 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R611 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R612 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R613 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R614 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R615 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R617 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R618 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R620 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R621 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R622 0RH0471D622 4.7 1/10W 5 D.R/TP
R623 0RH0471D622 4.7 1/10W 5 D.R/TP
R624 0RH0471D622 4.7 1/10W 5 D.R/TP
R625 0RH0471D622 4.7 1/10W 5 D.R/TP
R626 0RH0471D622 4.7 1/10W 5 D.R/TP
R627 0RH0471D622 4.7 1/10W 5 D.R/TP
R628 0RH0471D622 4.7 1/10W 5 D.R/TP
R629 0RH0471D622 4.7 1/10W 5 D.R/TP
R630 0RH0471D622 4.7 1/10W 5 D.R/TP
R631 0RH0471D622 4.7 1/10W 5 D.R/TP
RA201 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA202 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA203 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA204 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA401 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA402 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA403 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA404 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA405 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA406 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA407 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA408 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA409 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA410 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
RA411 0RHZTCZ001D RCA86TRJ22R0 SMART 22OHM 1/1
J104 6612J10001C "PPJ203-01 PARK ELEC. R/A,1P,"
J106 6612B00017B "KJA-DN-0-0022 KSD S-VHS,4P,R"
DATE: 2004. 10. 05.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
J601 6612TAH002A DC-001 UNITOP DC-001 2.0MM (
X202 6202TST001H SX-1 SUNNY 27MHZ +/- 30 PPM
X401 6202TST001A "SX-1 SUNNY ,SMS, 14.31818MHZ"
X501 6202TST001E SX-1 SUNNY CHIP 24MHZ 30PPM
LED701 0DLLT0208AA LITEON LTST-C155KGJSKT R/TP
LED702 0DLLT0208AA LITEON LTST-C155KGJSKT R/TP
LED703 0DLLT0208AA LITEON LTST-C155KGJSKT R/TP
LED704 0DLLT0208AA LITEON LTST-C155KGJSKT R/TP
LED705 0DLLT0208AA LITEON LTST-C155KGJSKT R/TP
R701 0RJ2701D677 2.7K OHM 1/10 W 5% 1608 R/TP
R702 0RJ2701D677 2.7K OHM 1/10 W 5% 1608 R/TP
R703 0RJ7501D677 7.5K OHM 1/10 W 5% 1608 R/TP
R704 0RJ7501D677 7.5K OHM 1/10 W 5% 1608 R/TP
SW701 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW702 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW703 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW704 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW705 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW706 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
C901 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C902 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C903 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C904 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C905 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C906 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C907 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C908 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
D901 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D902 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D903 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D904 0DS226009AA KDS226 TP KEC SOT-23 80V 30
L901 6210TCE001B HH-1H3216-500JT CERATEC 3216
L904 6210TCE001B HH-1H3216-500JT CERATEC 3216
ZD901 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
ZD904 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
- 25 -
OTHERs
CONTROL BOARD
USB BOARD
