Dell 2217H - Page 14

14 | About Your Monitor
* Color gamut (typical) is based on CIE1976 (82% NTSC) and CIE1931 (72% NTSC) test
standards.
Resolution Specifications
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset resolution 1920 x 1080 at 60 Hz
Supported Video Modes
Video display capabilities (VGA,
HDMI & DP playback)
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Connectivity • 1 x DP 1.2
• 1 x HDMI 1.4
• 1 x V
GA
• 1 x US
B 3.0 port - Upstream
• 2 x USB 3
.0 port - Side
• 2 x USB 2.0 port - Bottom
Border width (edge of
mo
nitor to active area)
11.4 mm (Top/Left/Right)
18.1 mm (Bottom)
11.6 mm (Top/Left/Right)
18.2 mm (Bottom)
Adjustability
Height adjustable stand
Tilt
Swivel
Pivot
130 mm
-5° to 21°
-45° to 45°
90° (clockwise)
Dell Display Manager
Compa
tibility
Yes
Security Security lock slot (cable lock sold separately)
Model P2217H/P2317H/P2317HWH/P2417H/P2717H
Model P2217H/P2317H/P2317HWH/P2417H/P2717H
