About Your Printer
Understanding Printer Parts
Understanding the Operator Panel
Choosing the Right Cable
Understanding Printer Parts
Part Description
1 Front exit Slot from where the paper exits the printer.
2 Output bin extender Support for the paper as it exits the printer.
3 Multipurpose feeder cover Door to gain access to the multipurpose feeder.
4 Standard tray (Tray 1) Standard paper tray that can hold 250 sheets of paper.
5 Optional 550-sheet drawer
(Tray 2)
Tray that can be purchased separately to increase the amount of blank paper that your
printer can hold.
6 Memory access door Door to access the printer memory.
7 Door release button Button to open the front cover of the printer.
8 Operator panel Panel on the printer to control print jobs.
9 Multipurpose feeder Tray to manually load various paper types such as envelopes.
