3. Press the button on the base of the imaging drum and pull the toner cartridge assembly up and out using the handle.
4. Lift the base of the imaging drum kit and gently pull it up and slide it out of the printer.
5. Remove the jammed paper.
6. Install the toner cartridge assembly into the imaging drum kit by aligning the white rollers on the toner cartridge with
the white arrows on the tracks of the imaging drum kit and pushing the toner cartridge in as far as it will go. The
cartridge clicks into place when correctly installed.
CAUTION: The inside of the printer might be hot. To reduce the risk of injury from a hot component,
allow the surface to cool before touching it.
CAUTION: The inside of the printer might be hot. To reduce the risk of injury from a hot component,
allow the surface to cool before touching it.
