24 Rack Installation Guide
Figure 1-9. Securing the Cables to the Rack
Replacing the Rack Doors
See the procedures for replacing doors in the documentation provided
with your rack cabinets.
This completes the rack installation of your system.
1 I/O cable enumerator
(segments 1-8)
2 I/O cable enumerator
(segments 9-16)
3 cable notches
(3 per segment)
4 fiber optic cable
connectors (16)
5 fiber optic cables (16) 6 strain-relief bar
7 Velcro tie wraps (15) 8 power cables 9 vertical rail
4
6
3
5
8
7
2
9
1
