Replacing the Base Panel
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Connect the battery cable to the battery-cable connector.
2 Align the tabs on the base panel with the slots on the computer base and
snap the base panel into place.
3 Tighten the captive screws that secure the base panel to the computer
base.
17
