Replacing the logo board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Procedure
1 Connect the tron-light cables, the logo-board cable, and the Alienhead cable
to the logo board.
2 Push the latch that secures the Alienhead cable to the logo board.
3 Turn the logo board over.
4 Using the alignment post, place the logo board on the display back-cover
and antenna assembly.
5 Align the screw holes on the logo board with the screw holes on the display
back-cover and antenna assembly.
6 Replace the two screws (M2x3) that secure the logo board to the display
back-cover and antenna assembly.
Post-requisites
1 Replace the display bezel.
2 Replace the display assembly.
3 Follow the procedure from step 2 to step 15 in “Replacing the system board”.
4 Replace the memory modules.
5 Replace the computer base.
6 Replace the rear-I/O cover.
7 Replace the solid-state drive.
8 Replace the wireless card.
9 Follow the procedure from step 4 to step 7 in “Replacing the hard drive”.
10 Replace the base cover.
103
