Dell Alienware m16 R1 AMD - External Ports; Internal Slots

External ports
The following table lists the external ports of your Alienware m16 R1 AMD.
Table 5. External ports
Description Values
Network port
One RJ-45 port
USB ports
● One USB 3.2 Gen 1 port
● One USB 3.2 Gen 1 port with PowerShare
● Two USB 3.2 Gen 2 Type-C ports with DisplayPort for
computers shipped with NVIDIA GeForce RTX 4080, RTX
4090, and AMD RX 7600M XT graphics card
● One USB 3.2 Gen 2 Type-C ports with DisplayPort and one
USB 3.2 Gen 2 Type-C ports for computers shipped with
NVIDIA GeForce RTX 4060/4070 graphics card
Audio port
One universal audio jack (RCA, 3.5 mm)
Video port
● One HDMI 2.1 port
● One mini-DisplayPort
Media-card reader
One SD-card slot
Power-adapter port
One 7.40 mm x 5.10 mm DC-in
Security-cable slot
Not supported
Internal slots
The following table lists the internal slots of your Alienware m16 R1 AMD.
Table 6. Internal slots
Description Values
M.2
● One M.2 2230 and two M.2 2280 solid-state drive slots, for
computers shipped with NVIDIA GeForce RTX 4080, RTX
4090, and AMD RX 7600M XT graphics card
● Two M.2 2280 solid-state drive slots, for computers shipped
with NVIDIA GeForce RTX 4060/4070 graphics card
NOTE: To learn more about the features of different types
of M.2 cards, search in the Knowledge Base Resource at
www.dell.com/support.
11
