Dell C2665dnf Specifications

Product Specifications (2 of 2)
Connectivity Standard interfaces
High speed USB 2.0, Gigabit Ethernet port, USB Embedded Host Port for USB Direct Print and Scan to, Near
Field Communication (NFC), Wireless & Wifi Direct (Optional Wireless Adapter)
Operating Systems Windows Microsoft
®
Windows XP/2003 Server, Windows 8, Windows 8 RT, Windows 7 (32/64 bit), Windows Vista
(32/64 bit), Windows Server 2008 R1 & R2, Windows 8.1 (available in Nov, 2013), Windows XP (32/64 bit),
Windows 2003 Server, Windows Cluster Server Environment, Windows 2012 Server
Macintosh Macintosh OS 10.5 to 10.8
Others
SUSE
®
Linux Enterprise Desktop 10, 11; Red Hat Linux Enterprise Desktop 5, 6; Nowell
®
Netware Support;
SAP R/3 Release 4.6B onwards; Citrix
®
Presentation Server™ 4.5, Citrix XenApp 5.0 to 6.5
Standard media types, sizes Standard tray
Media types and weights supported
Plain paper (60-90 gsm), Thicker paper (91-105 gsm), Heavier paper-L (106-163 gsm), Heavier paper-H
(164 - 216 gsm), Preprint (60 - 163 gsm), Letterhead (60-163 gsm), Prepunched (60-105 gsm), Cardstock
(106-216 gsm), Coated paper, Coated paper (95-216 gsm), Recycled paper
Media sizes A4 SEF, B5 SEF, A5 SEF, US Letter SEF, Executive SEF, Foilio (8.5”x 13”) SEF, US Legal SEF;
Custom size: 148 mm - 215.9 mm (W), 210 mm - 355.6 mm (L)
Multipurpose tray
Media types and weights supported
Plain paper (60-163 gsm), Preprinted (60-163 gsm), Letterhead (60-163 gsm), Prepunched (60-105 gsm),
Cardstock (106-216 gsm), Coated paper-L (95-216 gsm), Heavier paper (164-216 gsm), Recycled, Label
paper, Envelope, Hagaki cards
Media sizes
A4 Short Edge Feed (SEF), B5 SEF, A5 SEF, US Letter SEF, Executive SEF Folio (8.5” x 13”) SEF, US Legal SEF,
Envelope Com-10 (SEF), Envelope Monarch (SEF), Envelope DL (LEF/SEF), C5 (SEF), Post Card;
Custom size: 76.2 mm – 216 mm (W), 127 mm – 355.6 mm (L)
Optional tray
Media types and weights supported
Plain paper (60-90 gsm), Thicker paper (91-105 gsm), Heavier paper-L (106-163 gsm), Heavier paper-H
(164 - 216 gsm), Preprint (60 - 163 gsm), Letterhead (60-163 gsm), Prepunched (60-105 gsm), Cardstock
(106-216 gsm), Coated paper, Coated paper (95-216 gsm), Recycled Paper, Labels
Media sizes
A4 SEF, B5 SEF, A5 SEF, US Letter SEF, Executive SEF, Foilio (8.5”x 13”) SEF, US Legal SEF
Custom size: 148 mm - 215.9 mm (W), 210 mm - 355.6 mm (L)
Duplexer
Media types and weights supported Plain paper (60-90 gsm), Thicker paper (91-105 gsm), Heavier paper-L (106-163 gsm), Recycled paper,
Coatled paper-L (95-105 gsm), Coated paper-M (106-163 gsm)
Media sizes US Letter SEF, Executive SEF, A5 SEF, A4 SEF, B5 SEF, US Legal 13 SEF, US Legal 14 SEF
Custom size: 148.5 mm - 215.9 mm (W), 210 mm - 355.6 mm
Printable area 207.9 mm x 347.6 mm
Paper handling Standard input sources 250-sheet standard tray, 150-sheet multipurpose tray
Additional input capacity 550-sheet option drawer
Maximum input capacity 950 sheets (via addition of one 550-sheet optional drawer)
Duplexer Automatic two-side printing (default)
Output capacity 250 sheets
Physical specifications Dimensions (W x D x H) Printer: 439 mm x 529.5 mm x 558 mm; Shipping: 570 mm x 686 mm x 706 mm
Weight Printer: 32.6 kg with consumable; Shipping: 37.5 kg
Operating environment Temperature: 5°C to 32°C; Relative humidity: 15% to 85% RH, non-condensing; Altitude: ≤ 3,100 m
Storage Temperature: 0°C to 35°C; Relative humidity: 5% to 90% RH, non-condensing; Altitude: ≤ 3,100 m
Acoustic (Pressure/Power) Printing - 52.5 dB
7
/6.95 B
7
; Standby - 27 dB
7
/4.3 B
7
Power specifications Voltage (230 VAC model) 220 to 240 VAC, 50 Hz ± 3 Hz/60 Hz ± 3 Hz
Power consumption Printing mode: 750 W; Power saver mode: 3.5 W (Deep sleep)
Typical power consumption
8
2.7 kWh
Environmental compliance ErP Lot 4 and 6, RoHS-compliant
9
, ENERGY STAR
®
qualified
10
, Blue Angel (Germany) UZ171, WEEE, GS Mark
(Germany)
Supported languages English, French, German, Italian, Spanish, Dutch, Danish, Norwegian and Swedish
Safety certifications
IEC60950-1:2005 2
nd
Edition (International); EN60950-1:2006/A11:2009/A1:2010/A12:2011; EC60825-1 2
nd
(Laser); SEMKO (Nordic); CE Mark (EU); UL/cUL listed (UL60950-1 2
nd
Edition, US/Canada); FDA/DHHS (21
CFR, Chapter 1, Subchapter J)
Other certifications
CE mark (EU countries) EMC/Safety Standard Class B, EN55022:2006; EN55022:2010; EN61000-3-2:2006;
+ A1:2009 + A2:2009; EN 61000-3-3:2008; EN 55024:1998+A1:2001/A2:2003; FCC CFR Titl 47, Part 15
Class B (USA); ICES-003, Issue 4 (Canada); WHQL, Citrix, SAP, Novell, USB, WiFi, Google Cloud Print,
Apple Airprint
Contents in box
Dell Colour Multifunction Printer – C2665dnf, Ship-With Black Cartridge and Colour (Cyan, Magenta, Yellow) Cartridges (1,200-page yield
11
), Power
cord, Quick Setup Sheet, Software and Instructions CD, Product Information Guide
1. Measured in accordance with ISO IEC 27434/35 methodology. Actual print speed may vary depending upon system configuration, software application and document complexity.
2. 1 MB means 1 million bytes, 1 GB means 1,000 megabytes or 1,000,000,000 bytes; total accessible capacity varies depending on operating environment.
3. Duty cycle is defined as the maximum number of imaged outputs a device could deliver in a month. This metric provides a comparison of robustness in relation to other Dell printers and multifunction printers.
4. Configuration of the printer and the mobile device must be on the same authorized wireless network.
5. AirPrint-enabled printers work with iPad, iPhone (3GS or later), and iPod touch (3rd generation or later) running iOS 4.2 or later.
6. Supports the following file formats: Microsoft Oce (XLS, XLSX, PPT, PPTX, DOC, DOCX), JPEG, TIFF, PNG, PDF, Google Docs, ODT/FODT, ODS/FODS, ODP/FODP.
7. Tested in accordance with ISO 7779 and reported in accordance with ISO 9296. Acoustics - Declared noise emission values of computer and business equipment
8. For the Typical Energy Consumption value calculation details please visit: www.energystar.gov/ia/products/fap/IE_TEC_Test_Procedure.pdf
9. Meets the requirements of the EU RoHS Directive 2011/65/EU on the Restriction of the use of certain Hazardous Substances (RoHS).
10. For details on energy eciency of ENERGY STAR
®
qualified products, refer to: www.energystar.gov
11. Toner yield based on testing in accordance with ISO/IEC 19798. Yields vary with usage and environmental conditions.
©2013 Dell Corporation Limited. Dell, the Dell logo and Dell Toner Management System are registered trademarks or trademarks of Dell Inc. Other trademarks and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the marks and names of others. Microsoft, Windows and Windows NT are registered trademarks or trademarks of
Microsoft Corporation. Android and Google Cloud Print are registered trademarks of Google Inc. iPad, iPhone, iPod, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. AirPrint and the
AirPrint logo are trademarks of Apple Inc. Dell Products, Dell House, The Boulevard, Cain Road, Bracknell, Berkshire, RG12 1LF, UK. Product availability varies by country. Please contact your Dell representative for more
information.
Specifications are subject to change without notice. Dell cannot be responsible for errors and omissions in typography or photography.
A13002312 - C2665dnf - Oct 2013

Dell C2665dnf Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	27 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	16 s
Time to first copy (color, normal)	20 s
Copy speed (black, normal quality, A4)	27 cpm
Scan to	Cloud, E-mail, FTP, SMB, USB
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, TIF
Maximum scan resolution	9600 x 9600 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 1200 DPI
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Recommended duty cycle	700 - 4000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PCL XL, PDF 1.6, PostScript 3
Printer management	Dell Printer Configuration Web Tool, Dell ColourTrack 2.2, Dell Toner Management System, Dell Open Print Driver (OPD), Dell OpenManage TM Printer Manager v2 (OMPM)
Security features	IKev1, EWS, IPv4, Fax/I/O
Cabling technology	10/100/1000Base-T(X)
Authentication method	NTLM, SNMP v3, LDAP Kerberos
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Box, Dropbox, Google Drive, Sky Drive
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Sound pressure level (printing)	52.5 dB
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	950 sheets
Envelopes sizes	C5, DL, Monarch
Custom media width	148.5 - 215.9 mm
Custom media length	210 - 355.6 mm
Duplex media weight	60 - 163 g/m²
Paper tray media types	Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Control type	Touch
Product color	Black
Display diagonal	4.3 \
Display resolution	272 x 480 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	14.5 W
Power consumption (PowerSave)	3.5 W
Power consumption (average operating)	2700 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	RedHat EL Linux 5.0
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	Blue Angel, RoHS, ENERGY STAR
Certification	EC60950-1:2005, EN60950-1:2006/A11:2009/A1:2010/A12:2011; EC60825-1 2-nd (Laser); SEMKO (Nordic); CE Mark (EU); UL/cUL (UL60950-1 2); FDA/DHHS (21CFR, Chapter 1, Subchapter J), CE mark (EU countries) EMC/Safety Standard Class B, EN55022:2006, EN55022:2010, EN61000-3-2:2006, \\r + A1:2009 + A2:2009, EN 61000-3-3:2008, EN 55024:1998+A1:2001/A2:2003, FCC CFR Titl 47, Part 15 Class B (USA), ICES-003, Issue 4 (Canada), WHQL, Citrix, SAP, Novell, USB, WiFi, Google Cloud Print, Apple Airprint
Package depth	686 mm
Package width	570 mm
Package height	706 mm
Package weight	37500 g
Operating altitude	0 - 3100 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	5 - 32 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	529.5 mm
Width	439 mm
Height	558 mm
