Dell C7016H - Display and Electrical Specifications

About Your Monitor 21
Viewing angle:
Horizontal 176° typical
Vertical 176° typical
Luminance output 400 cd/m² (typical)
Contrast ratio 4000 to 1 (typical)
Faceplate coating Antiglare with hard-coating 2H
Backlight LED light bar system
Response Time 8 ms typical (gray to gray)
Color Depth 1.07 billion colors
Color Gamut 86 % (typical) *
* C7016H color gamut (typical) is based on CIE1976 (86 %) and CIE1931 (72 %) test
standards.
Resolution Specifications
Model number C7016H
Scan range
• Horizontal 30 kHz to 83 kHz (automatic)
• Vertical 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
1920 x 1080 at 60 Hz
Electrical Specifications
Model number C7016H
Video input signals • Analog RGB: 0.7 Volts ± 5 %, 75 ohm input impedance
• DisplayPort, 600mV for each differential line, 100 ohm input
impedance per differential pair
• HDMI (MHL), 600mV for each differential line, 100 ohm
input impedance per differential pair
Synchronization input
signals
Separate horizontal and vertical synchronizations, polarity-free
TTL level, SOG (Composite SYNC on green)
AC input voltage /
frequency / current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 4.0 A (Max)
Inrush current 120 V: 40 A (Max.)
240 V: 80 A (Max.)
