Dell D14U - Installing the Processor

CAUTION: When removing the processor, do not touch any of the pins inside the socket or allow any objects
to fall on the pins in the socket.
3. Gently lift the processor from the processor socket.
Installing the processor
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the processor and provides a visual representation of the installation procedure.
Steps
1. Align the pin-1 corner of the processor with the pin 1 corner of the processor socket, and then place the processor in the
processor socket.
46
Removing and installing components
