10 Quick Reference Guide
About Your Computer
Front View
1 display latch 2 display 3 power button
4 device status lights 5 keyboard 6 touch pad
7 fingerprint reader (optional) 8 speaker 9 touch pad/track stick buttons
10 track stick 11 keyboard status lights 12 volume control buttons
13 ambient light sensor (ALS)
NOTE: The ALS is disabled
when you receive the computer.
For more information about the
ALS, see the computer
User’s Guide.
14 mute button
2
5
3
12
13
4
11
7
8
14
9
10
6
1
