94 Appendix
www.dell.com | support.dell.com
Video
Video controller integrated Intel 3D Extreme Graphics
Audio
Audio controller integrated audio
Network
Network controller integrated 10/100 Ethernet
Controls and Lights
Power control push button
Front-panel power light solid green for power-on state; blinking green for
standby state
Hard-drive access light green
Power
DC power supply:
Wattage 200 W or 250 W
Heat dissipation 682 or 853 BTU (fully-loaded computer without
monitor)
Voltage (see page 11 for
important voltage setting information)
100 to 120 V at 60 Hz; 200 to 240 V at 50 Hz
Backup battery 3-V CR2032 coin cell
Physical
Height x Width x Depth 36.8 x 18.4 x 42.6 cm
(14.5 x 7.25 x 16.75 inches)
Weight 10.4 kg (23 lb)
Environmental
Temperature:
Operating 10° to 35°C (50° to 95°F)
NOTE: At 35°C (95°F), the maximum operating altitude
is 914 m (3000 ft).
Storage –40° to 65°C (–40° to 149°F)
