Removing and Installing Parts 91
5
Disconnect the FlexBay USB cable on the back of the Media Card Reader from the Media
Card Reader connector on the system board (see page 62) and route the cable through the
cable routing clip.
6
Slide the drive latch release toward the bottom of the computer and, without releasing the
drive latch release, slide the Media Card Reader out through the front of the computer.
7
Replace the drive panel (see page 79).
8
Replace the computer cover (see page 99).
Media Card Reader
sliding plate
drive latch release
