Removing and Installing Parts 105
6
If you are installing a new CD/DVD drive rather than replacing a drive, remove the front-
panel inserts (see page 98).
7
Check all cable connections, and fold cables out of the way to provide airflow for the fan and
cooling vents.
8
Close the computer cover (see page 107).
NOTICE: To connect a network cable, first plug the cable in to the network device and then plug it in to
the computer.
9
Connect your computer and devices to their electrical outlets, and turn them on.
See the documentation that came with the drive for instructions on installing any software
required for drive operation.
10
Enter system setup (see page 113) and select the appropriate
Drive
option.
11
Verify that your computer works correctly by running the Dell Diagnostics (see page 55).
power cable
data cable
