Dell Dimension 8400 - Removing a Hard Drive

94 Removing and Installing Parts
www.dell.com | support.dell.com
Removing a Hard Drive
1 Disconnect the power and data cable from the drive and from the system board.
2 Press in on the tabs on each side of the drive and slide the drive up and out.
tabs (2)
hard drive
