Dell E173FP - Plug and Play

1 Video-Red
2 Video-Green
3 Video-Blue
4 GND
5 Self-test
6 GND-R
7 GND-G
8 GND-B
9 PC5V
10 GND-sync
11 GND
12 DDC data
13 H-sync
14 V-sync
15 DDC clock
Plug and Play Capability
You can install the display in any Plug and Play-compatible system. The display automatically provides the computer system
with its Extended Display Identification Data (EDID) using Display Data Channel (DDC) protocols so the system can configure
itself and optimize the display settings. If desired, the user can select different settings, but in most cases display installation
is automatic.
