Dell E176FPc
27
Screw AC ground line as the
figure and should be laid at the
left of screw pillar.
Note: The green line can’t be
pressed under the power board.
Note: The pins can’t gore the
blue and purple lines.
The end
The angle between CCFL line
and vertical direction should be
45 degree.
ground
Screw pillar
Affix black tapes for AU
and SAMSUNG panel
Affix 50mm black
tapes for
SAMSUNG
To Next Page
