Back to Contents Page
Using Your Monitor Stand
Dell™E178FPFlatPanelMonitorUser'sGuide
Attaching the Stand
Organizing Your Cables
Using the Tilt
Removing the Stand
Attaching the Stand
1. Place the stand on a flat surface.
2. Fit the groove on the back of the monitor onto the two teeth of the upper stand.
3. Lower the monitor so that the monitor mounting area snaps on/locks to the stand.
Organizing Your Cables
After attaching all necessary cables to your monitor and computer, (See Connecting Your Monitor for cable attachment,) use the cable holder to
neatly organize all cables as shown above.
Using the Tilt
With the built-in pedestal, you can tilt the monitor to best suit your viewing needs.
NOTE: Stand is detached when the monitor is shipped from the factory.
