NOTE: In some environments where the Edge Gateway may be installed, a more robust mounting method is required. For
example, for mounting in marine applications, it is recommended to use only the standard— mount bracket. The
recommendation is due to the presence of vibrations unique to the marine environment.
1. Use USB cables to connect a display, keyboard, and mouse.
NOTE: USB power is limited to 0.6 A/3 W for USB 3.0 port and 0.4 A/2 W for USB 2.0 port to ensure that the Edge
Gateway is within the allowed 13 W PoE Class 0 range.
2. Connect an Ethernet cable to Ethernet port one.
3. Connect the antennas depending on the configuration ordered (optional).
NOTE:
The antennas supported in the Edge Gateway vary depending on the configuration ordered. Antennas are
available in the accessory box shipped with the Edge Gateway.
14 Installing your Edge Gateway
