Figure 69. Install screws and nuts on side panel
Figure 70. Install screws and nuts on bottom panel
NOTE: Reuse screws removed from step 1. Nuts are included in the kit.
7. Remove the screws of the front I/O panel, as shown in the following figure. Remove the 4-port COM cable from the front
I/O panel.
Installation procedure for 2x GbE LAN uFM module
41
