Table 14. UEFI iSCSI Settings screen details (continued)
Option Description
iSCSI Device1 Enables or disables the iSCSI device. When disabled, a UEFI boot option is created for
the iSCSI device automatically. This is set to Disabled by default.
iSCSI Device1 Settings Enables you to control the configuration of the iSCSI device.
Table 15. ISCSI Device1 Settings screen details
Option Description
Connection 1 Enables or disables the iSCSI connection. This option is set to Disable by default.
Connection 2 Enables or disables the iSCSI connection. This option is set to Disable by default.
Connection 1 Settings Enables you to control the configuration for the iSCSI connection.
Connection 2 Settings Enables you to control the configuration for the iSCSI connection.
Connection Order Enables you to control the order for which the iSCSI connections will be
attempted.
Integrated Devices
To view the Integrated Devices screen, power on the system, press F2, and click System Setup Main Menu > System BIOS
> Integrated Devices.
Table 16. Integrated Devices details
Option Description
User Accessible USB Ports Configures the user accessible USB ports. Selecting Only Back Ports On
disables the front USB ports; selecting All Ports Off disables all front and
back USB ports; selecting All Ports Off (Dynamic) disables all front and back
USB ports during POST. This option is set to All Ports On by default.
When user accessible USB ports are set to All Ports Off (Dynamic) the
Enable Front Ports Only option is enabled.
● Enable Front Ports Only: Enables or disables the front USB ports during
the operating system runtime.
The USB keyboard and mouse still function in certain USB ports during the
boot process, depending on the selection. After the boot process is complete,
the USB ports will be enabled or disabled as per the setting.
iDRAC Direct USB Port The iDRAC Direct USB port is managed by iDRAC exclusively with no host
visibility. This option is set to ON or OFF. When set to OFF, iDRAC does not
detect any USB devices installed in this managed port. This option is set to On
by default.
Internal SD Card Port Enables or disables the internal SD card port of the Internal Dual SD Module
(IDSDM). This option is set to On by default.
Internal SD Card Redundancy Configures the redundancy mode of the Internal Dual SD Module (IDSDM).
When set to Mirror Mode, data is written on both SD cards. After failure of
either card and replacement of the failed card, the data of the active card is
copied to the offline card during the system boot.
When Internal SD Card Redundancy is set to Disabled, only the primary SD
card is visible to the operating system. This option is set to Disabled by
default.
Internal SD Primary Card By default, the primary SD card is selected to be SD Card 1. If SD Card 1 is not
present, then the controller selects SD Card 2 to be the primary SD card.
14 Pre-operating system management applications
