Setting Up a PS Series Storage Array
Turn on Power to the Array
Before turning on power, allow enough time for the
array to adjust to ambient temperature and humidity
(for example, overnight).
The power switch on each power supply module is
located below the power plug. The switch is
oriented vertically. Turn on power to both power
supply modules (in any order).
Note: Batteries will start to charge and some
hardware components may start to synchronize
when power is turned on. Array LEDs will indicate
this normal activity.
6
Printed in U.S.A.
Printed on recycled paper.
R5DM1 rev.A00
Hardware Installation is Complete.
See the Installation and Setup guide to configure the array
software.
Information in this document is subject to change without
notice.
Reproduction in any manner whatsoever without the written
permission of Dell EqualLogic is strictly forbidden.
The Dell EqualLogic logo is a trademark of Dell, Inc.
Copyright 2011 Dell, Inc. All rights reserved.
Notes, Cautions, and Warnings
A NOTE indicates important information that helps you make
better use of your computer.
A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
A WARNING indicates a potential for property damage, personal
injury, or death.
Setting Up a PS Series Storage Array (continued)
Connect the Array to the Network
Recommended Configuration: For high performance and
availability, connect network cables to all the network
interfaces and distribute the connections across multiple
network switches. The switches must be connected with
interswitch links that have sufficient bandwidth.
5
Switch 0
Switch 1
CM0
CM1
