154 Adding and Replacing Parts
4
Disconnect the antenna cables from the
WLAN
card.
5
Release the
WLAN
card by pushing the metal securing tabs toward the
back of the computer until the card pops up slightly.
6
Lift the
WLAN card
out of its system board connector.
1 antenna cable connectors (2) 2 WLAN card
1
2
