Adding and Replacing Parts 161
Replacing a WPAN Card
NOTICE: The connectors are keyed to ensure correct insertion. If you feel
resistance, check the connectors on the card and on the system board, and realign
the card.
NOTICE: To avoid damage to the WPAN card, never place cables under the card.
1
Insert the
WPAN
card connector into the system board connector labeled
"WPAN" at a 45-degree angle.
2
Press the other end of the
WPAN
card down into the securing tabs until
the card clicks into place.
3
Connect the blue antenna cable to the
WPAN
card.
4
Secure unused antenna cables in the protective mylar sleeve.
5
Replace the cover and tighten the captive screws.
Internal Card With Bluetooth
®
Wireless
Technology
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on the back of the computer).
NOTICE: To help prevent damage to the system board, you must remove the battery
from the battery bay before you begin working inside the computer.
If you ordered a card with Bluetooth wireless technology with your computer,
it is already installed.
Removing the Card
1
Follow the procedures in "Before You Begin" on page 137.
2
Remove the hinge cover (see "Hinge Cover" on page 143).
3
Disconnect the cable on the card.
4
Grasp the connector end of the card and slide it out from under the
securing tabs.
