Dell Inspiron 1521 - S-Video and Standard Audio

Using Multimedia 63
S-Video and Standard Audio
1 Turn off the computer and the TV and/or audio device that you want to
connect.
NOTE: If your TV or audio device supports S-video but not S/PDIF digital audio, you
can connect an S-video cable directly to the S-video TV-out connector on the
computer (without the TV/digital audio adapter cable).
2 Plug one end of the S-video cable into the S-video output connector on
the computer.
3 Plug the other end of the S-video cable into the S-video input connector
on your TV.
1 audio connector 2 S-video TV-out connector
1 standard S-video cable 2 standard audio cable
1
2
1
2
