158 Adding and Replacing Parts
4
Disconnect the two antenna cables from the
WWAN
card.
5
Release the
WWAN
card by pushing the metal securing tabs toward the
back of the computer until the card pops up slightly.
6
Lift the
WWAN card
out of its system board connector.
1 antenna cable connectors (2) 2 WWAN card
1
2
