Using Multimedia 65
1 Turn off the computer and the TV and/or the audio device that you want
to connect.
2 Connect the composite video adapter to the S-video TV-out connector on
your computer.
3 Plug one end of the S-video cable into the S-video output connector on
the composite video adapter.
4 Plug the other end of the S-video cable into the S-video input connector
on the TV.
5 Plug one end of the S/PDIF digital audio cable into the digital audio
connector on the composite video adapter cable.
1 composite video adapter 2 S-video cable
3 S/PDIF digital audio cable
1 composite video adapter 2 S-video cable
1
2
3
1
2
