Dell Inspiron 5735 - Procedure

Removing the Display Panel | 63
Procedure
1 Remove the screws that secure the display panel to the display back-cover.
2 Gently lift the display panel and turn it over.
3 Peel off the tape adhered over the display cable.
4 Disconnect the display cable from the display panel.
1 display panel 2 screws (12)
3 display back-cover
1 display cable 2 display panel
3 tape
2
3
1
1
3
2
