3. To remove the GPS module:
a. Disconnect the GPS antenna cable from the module. [1]
b. Release the GPS module from its connector to the system board. [2]
c. Pry the GPS module retention latch upwards and remove the GPS module from the computer. [3]
[4]
Installing the Global Positioning System (GPS) Module
1. Insert the GPS module into its slot and align it with the connector to the system board.
2. Connect the GPS module antenna cable.
3. Install:
a. bottom cover
b. battery
4. Follow the procedures in After Working Inside Your computer.
Removing the USH Daughter Board
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. bottom cover
c. hard drive
d. ExpressCard
25
