Description Option 1 Option 2 Option 3 Option 4
Vertical view angle 10/30 degrees (min) 80/80 degrees (min) 80/80 degrees (min)
• Sharing Mode:
80/80 degrees
(min)
• Privacy Mode
(brightness <
40%) : 30/30
degrees (max)
Pixel pitch 0.2151 mm 0.153 mm 0.153 mm 0.153 mm
Power consumption
(maximum)
2.85 W 2.0 W 4.8 W
• Sharing Mode: 2.3
W
• Privacy Mode
(brightness <
40%) : 2.4 W
(max)
Anti-glare vs glossy finish Anti-glare Anti-glare Anti-glare Anti-glare
Touch options Non-touch Non-touch Touch (no active pen
support)
Non-touch
GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Latitude 7310.
Table 24. GPU—Integrated
Controller External display support Memory size Processor
Intel UHD Graphics • Two DisplayPort over USB
Type-C with Thunderbolt 3.0
port
• One HDMI 2.0 port
Shared system memory 10
th
Generation Intel Comet
Lake Core i5/i7 processors
Computer environment
Airborne contaminant level: G1 as defined by ISA-S71.04-1985
Table 25. Computer environment
Description Operating Storage
Temperature range
Normal ambient condition 25°C and
40~50% 0°C to Normal ambient condition
25°C and 40~50% 40°C (32°F to 104°F)
-40°C to 65°C (-40°F to 149°F)
Relative humidity (maximum)
Normal ambient condition 25°C and
40~50% 10% to Normal ambient condition
25°C and 40~50% 90% (non-condensing)
10% to 95% (non-condensing)
Vibration (maximum)
*
0.66 GRMS 1.30 GRMS
Shock (maximum)
140 G† 160 G†
Altitude (maximum)
0 m to 3048 m (0 ft to 10,000 ft) 0 m to 10,688 m (0 ft to 35,000 ft)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse when the hard drive is in use.
‡ Measured using a 2 ms half-sine pulse when the hard-drive head is in parked position.
Specifications of Latitude 7310
25
