8 About Your Computer
FILE LOCATION: S:\systems\Roush ATG\QRG\A00\EN\source\about.fm
DELL CONFIDENTIAL – PRELIMINARY 2/10/08 - FOR PROOF ONLY
1 track stick 2 left speaker
3 keyboard 4 device status lights
5 ambient light sensor (ALS) 6 keyboard status lights
7 display 8 microphone/camera
(optional)
9 display latch 10 volume controls
11 Dell Control Point (DCP) 12 power button
13 USB ports (2) 14 WiFi Catcher™
15 wireless switch 16 audio connectors (2)
17 right speaker 18 optical drive
19 finger print swipe reader 20 ExpressCard/CardBus slot
21 firewire (IEEE 1394a) port 22 contactless SmartCard reader
23 touch pad 24 media card reader
25 latch button 26 touch pad buttons
