Dell Latitude D505 Series User Manual

Keyboard: Dell Latitude D505 Series Service Manual
1 display see Mini RSL
2 center control cover H1371
3 palm rest (with touch pad) D1482
3. Remove the center control cover:
a. Open the display all the way (180 degrees) so that it lies flat against your
work surface.
b. Starting on the right side of the computer, use a plastic scribe to pry up
the center control cover. Lift it away from the computer, and lay it aside.
1 center control cover H1371
4. Remove the keyboard:
file:///F|/Service%20Manuals/Dell/Latitude/d505/keyboard.htm (2 of 4) [2/28/2004 8:13:47 AM]

Dell Latitude D505 Series Specifications

General

Processor	Intel Pentium M or Intel Celeron M
Graphics	Intel Extreme Graphics 2
RAM	256 MB to 2 GB DDR SDRAM
Storage	30 GB to 60 GB HDD
Display	14.1 inch XGA or SXGA+
Optical Drive	CD-ROM, DVD-ROM
Operating System	Windows XP Professional
Weight	5.5 lbs (2.49 kg)
Networking	10/100 Ethernet
Ports	2 x USB 2.0, VGA, Ethernet, modem
Battery Life	Varies with usage, typically 2-4 hours
