Dell Latitude D600 Service Manual

Memory Module, Mini PCI Card, and Modules: Dell Latitude D600 Service Manual
4. If a Mini PCI card is not already installed, go to step 5. If you are replacing a
Mini PCI card, remove the existing card:
a. Disconnect the Mini PCI card from any attached cables.
b. Release the Mini PCI card by spreading the metal securing tabs until the
card pops up slightly.
c. Lift the Mini PCI card out of its connector.
5. Align the new Mini PCI card with the connector at a 45-degree angle, and press
the Mini PCI card into the connector.
6. Connect the antenna cables from the Mini PCI card to the antenna connectors on
the computer.
NOTICE: The connectors are keyed for correct insertion; do not force the
connections.
1 antenna cables
file:///F|/Service%20Manuals/Dell/Latitude/d600/upgrades.htm (6 of 10) [2/28/2004 8:15:43 AM]

Dell Latitude D600 Specifications

General

RAM	256MB - 2GB DDR SDRAM
Graphics	ATI Mobility Radeon 9000
Operating System	Windows XP Professional
Chipset	Intel 855PM
Processor	Intel Pentium M
Display	14.1-inch
Resolution	1400x1050 (SXGA+) or 1024x768 (XGA)
Storage	20GB - 80GB HDD
Hard Drive Interface	IDE
Optical Drive	DVD-ROM or CD-RW/DVD combo drive
Ports	2 x USB 2.0, 1 x VGA, 1 x Ethernet, 1 x Modem
Battery	6-cell or 9-cell Lithium Ion
Networking	Ethernet, Modem, WiFi (802.11b/g)
Dimensions	12.2 x 9.9 x 1.2 inches (310 x 252 x 31 mm)
