Dell Latitude D600 Service Manual

Before You Begin: Dell Latitude D600 Service Manual
NOTE: Ensure that the computer is off and not in a power management mode.
If you cannot shut down the computer using the computer operating system,
press and hold the power button for 4 seconds.
4. If the computer is connected to a docking station, undock it.
5. Disconnect the computer from the electrical outlet.
6. To avoid possible damage to the system board, wait 10 to 20 seconds and then
disconnect any attached devices.
7. Disconnect all other external cables from the computer.
8. Remove any installed PC Cards from the PC Card slot.
9. Close the display and turn the computer upside down on a flat work surface.
NOTICE: To avoid damaging the system board, you must remove the main
battery before you service the computer.
10. Slide and hold the battery-bay latch release on the bottom of the computer, and
then remove the battery from the bay.
file:///F|/Service%20Manuals/Dell/Latitude/d600/begin.htm (2 of 7) [2/28/2004 8:15:41 AM]

Dell Latitude D600 Specifications

General

RAM	256MB - 2GB DDR SDRAM
Graphics	ATI Mobility Radeon 9000
Operating System	Windows XP Professional
Chipset	Intel 855PM
Processor	Intel Pentium M
Display	14.1-inch
Resolution	1400x1050 (SXGA+) or 1024x768 (XGA)
Storage	20GB - 80GB HDD
Hard Drive Interface	IDE
Optical Drive	DVD-ROM or CD-RW/DVD combo drive
Ports	2 x USB 2.0, 1 x VGA, 1 x Ethernet, 1 x Modem
Battery	6-cell or 9-cell Lithium Ion
Networking	Ethernet, Modem, WiFi (802.11b/g)
Dimensions	12.2 x 9.9 x 1.2 inches (310 x 252 x 31 mm)
