Dell Latitude E6430s Specifications

Discover leading-edge laptops at Dell.com/Latitude
1. Dell Latitude laptops are brominated flame retardant free (BFR-free) and polyvinyl chloride free (PVC-free); meeting the definition of BFR-/PVC-free as set forth in the iNEMI Position
Statement on the ‘Definition of Low-Halogen Electronics (BFR-/CFR-/PVC-free)’. Plastic parts contain less than 1,000 ppm (0.1%) of bromine (if the Br source is from BFRs) and less
than 1,000 ppm (0.1%) of chlorine (if the Cl source is from CFRs or PVC or PVC copolymers). All printed circuit board (PCB) and substrate laminates contain bromine/chlorine total
less than 1,500 ppm (0.15%) with a maximum chlorine of 900 ppm (0.09%) and maximum bromine being 900 ppm (0.09%).
2, WiFi enabled connection required. System must be on or in sleep mode with application running to update.
3. Oering available in select countries.
4. Not available in China or Russia.
5. Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.
6. Only available in emerging markets.
7. A 64-bit operating system is required to support 4GB or more of system memory.
8. Significant system memory may be used to support graphics, depending on system memory size and other factors
9. GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
10. Limited Hardware Warranty: For copy of Ltd Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see www.dell.com/warranty.
11. Based on preliminary Dell lab testing. Weights vary depending on configuration and manufacturing variability.
12. 1x8GB or 2x8GB memory options only avaialble via CFI service
Feature Technical Specification
Processor Options Intel® Core™ i3, i5 and i7 processors up to i7-35x0M
Operating System Options Genuine Windows
®
7 Home Basic
6
, Genuine Windows
®
7 Home Premium,
Genuine Windows
®
7 Professional, Genuine Windows
®
7 Ultimate
Linux Ubuntu 11.10
Memory
7
Options DDR3 SDRAM (1600MHz ) 2 slots supporting 2G, 4GB, 8GB
12
DIMMs
Chipset and Intel Responsiveness
Technologies
Mobile Intel
®
QM77 Express Chipset
Optional Intel Rapid Start Technology (SSD is required)
Optional Intel Smart Connect Technology
2
(SSD and Intel WLAN are required)
Graphics
8
Options Intel® HD Graphics 3000 for Intel Core i3 Processors
Intel® HD Graphics 4000 for Intel Core i3/i5/i7 3xxxM Processors
Display 14.0” HD (1366x768) Anti-Glare LED-backlit
Storage
9
Options 7200 rpm SATA up to 750GB, 5400 rpm SATA up to 320GB, 500GB SATA Solid State Hybrid
Encrypted (FDE/SED) FIPS, Opal 7200 rpm 320GB
4
Mobility Solid State up to 256GB, Encrypted Mobile Solid State up to 256GB
4
Dell Fast Response Free Fall Sensor and HDD Isolation (standard on motherboard)
E-Module Bay II Secondary HDD Option
Optical Drive Options DVD-ROM, DVD+/-RW via E-Modular Bay II
Multimedia Options High quality speakers, Stereo headphone/Microphone combo jack, Integrated noise reduc-
ing array microphones, Optional integrated HD video webcam and Dell Webcam Central
software
Battery Options 3-cell (32Whr) Lithium Ion battery with ExpressCharge™
6-cell (65Whr) Lithium Ion battery with ExpressCharge™
6-cell (58Wh) 3 Year Limited Hardware Warranty
10
Lithium Ion battery
9-cell (97Wh) Extended battery slice
3-cell (30Whr) E-Modular Bay II Battery
Power Options 65 Watt or 90W AC Adapter, 65W BFR/PVC Free AC Adapter
3
, 90W Auto/Air DC adapter
(optional)
Connectivity 10/100/1000 Gigabit Ethernet
Wireless LAN Options:
Intel® Centrino® Advanced-N 6205, Intel® Centrino® Ultimate-N 6300, Dell Wireless 1504
(802.11g/n 1x1), Dell Wireless 1540 (802.11n 2x2)
Bluetooth Option:
Dell Wireless 380Bluetooth® 4.0
Ports, Slots & Chassis Network connector (RJ-45), USB 2.0 (1) – 1 USB/eSATA combo; USB3.0 (2), Stereo head-
phone/Microphone combo jack, Memory card reader, 34 mm ExpressCard, Docking Con-
nector, VGA, mini HDMI, 1 Full and 2 Half Mini Card Slots
Optional SmartCard Reader/Contactless SmartCard Reader/Fingerprint Reader, Additional
USB 3.0 ports option via E-Modular Bay II
Input Device Options Dual pointing keyboard: standard or backlit
Multi-touch Touchpad
Dimensions & Weight
11
Width: 13.19”/335mm
Height: (front/back) 1.06”/26.8mm to 1.22”/30.09 mm
Depth: 8.80” / 223.3mm
Weight: 3.75lbs/1.70kg with a 3-cell battery, airbay and mSATA SSD
Regulatory and Environmental Compliance Regulatory Model: P19S Regulatory Type: P19S002
ENERGY STAR 5.2 (Windows OS)
EPEAT Gold (US/Canada); EPEAT Silver (France, Germany, Sweden)
Systems Management Intel® vPro™ Technology’s advanced management features (optional, requires Intel WiFi®
Link WLAN), TPM 1.2
4
Warranty & Support Services Limited Hardware Warranty
10
Standard 3-year Next Business Day On Site Service after
Remote Diagnosis
5
. Optional 3 year Dell ProSupport oers premium support from expert
technicians and 24x7 global availability
5
.
Configuration Services
5
Factory Image load. BIOS Customization. Hardware Customization, Asset Tagging and
Reporting.

Dell Latitude E6430s Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3340M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3300 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Internal memory	2 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 2 GB
HDD speed	5400 RPM
Storage media	HDD
Optical drive type	DVD±RW
Card reader integrated	-
Total storage capacity	320 GB
Number of HDDs installed	1
LED backlight	Yes
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Trial software	McAfee Security Center, Microsoft Office
Operating system installed	Windows 7 Professional
Processor code	SR0XB
Processor ARK ID	71257
Processor package size	37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	233.3 mm
Width	335 mm
Weight	1700 g
Height (rear)	30.9 mm
Height (front)	26.8 mm
