Back View
CAUTION: Do not block, push objects into, or allow dust to accumulate in the
cooling vents. Do not store your Dell computer in a low-airflow environment, such
as a closed briefcase, while it is running. Restricting the airflow can damage the
1 SecureDigital (SD) card slot 2 ExpressCard slot
3 air vents 4 video connector
5 USB connector 6 eSATA/USB connector
7 security cable slot 8 AC adapter connector
9 DisplayPort 10 power light/battery light
11 docking alignment mark 12 battery
13 network connector (RJ-45) 14 modem connector (RJ-11)
14 10
6
1
4
9
5
2
13
3
1112
7
8
