1-4 Dell Latitude System Information
DELL CONFIDENTIAL - Preliminary 1/24/00
(Rev. 11/3/98) FILE LOCATION:
J:\projects\10-01000\10-01288.del\users\joe\SIGs\Final\AMF\Multilin-
&RQQHFWLQJWKH$&$ GDSWHU
NOTE: A partially charged battery is already installed in the computer, but Dell recom-
mends that you attach the AC adapter now so that the battery can complete its charge
and the operating system setup can proceed without interruption.
To connect your computer to the AC adapter, perform the following steps:
1. Plug the AC adapter s attached c able into the AC adapter connector on the com-
puter (see Figure 1-2).
)LJXUH&RQQHFWLQJWKH$&$GDSWHU
2. Plug the AC adapter p ower cable into the AC adapter.
3. Plug the AC adapter power cable into an electrical outlet.
7XUQLQJ2QWKH&RPSXWHU
To turn on the computer, open the computer display and press the power button (see
Figure 1-3).
AC adapter
AC adapter
power cable
AC adapter connector
AC adapter cable
86EFPeb0.fm Page 4 Monday, January 24, 2000 12:52 PM
