Dell Latitude XT3 Manual

Media Base 7
Removing the Optical Drive
To remove the optical drive:
1
Remove the screw that secures the optical drive to the media base.
2 Use your screwdriver to slide the drive out of the media bay.
Installing the Optical Drive
To install the optical drive:
1
Insert the optical drive into the media bay on the media base.
2 Replace the securing screw that holds the optical drive in place.
Media Base Specifications
Physical
Height:
Without feet 14.75 mm (0.58 inch)
With feet 16.25 mm (0.64 inch)
Width 292.40 mm (11.51 inches)
Depth 191.50 mm (7.54 inches)
Weight 530 g (1.7 lbs)
Ports and Connectors
USB two 4-pin USB-2.0 compliant connector
Docking 144-pin connector

Dell Latitude XT3 Specifications

General

Memory	Up to 8GB DDR3
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Professional
Wireless	Wi-Fi 802.11 a/b/g/n, Bluetooth 3.0
Processor	Intel Core i5 or i7
Display	13.3-inch HD (1366 x 768)
Storage	Up to 320GB HDD
Battery	6-cell
Touchscreen	Yes
Ports	USB 2.0, HDMI, VGA, RJ-45
Webcam	Yes
