Dell M210X - Connecting Your Projector

8 Connecting Your Projector
2
Connecting Your Projector
CAUTION: Before you begin any of the procedures in this section, follow the
Safety Instructions as described on page 6.
1 USB remote connector 6 Audio output connector
2 VGA input (D-sub) connector 7 Audio input connector
3 HDMI connector 8 Security cable slot
4 S-video connector 9 Power cord connector
5 Composite video connector
3
4
5 6 7
1
2
8
9
