Dell OptiPlex 170L - Page 114


14. Replace the computer cover.

15. Connect your computer and devices to electrical outlets, and then turn them on.

See the documentation that came with the drive for instructions on installing any software required for drive operation.

Floppy Drive



Installing a Floppy Drive
1. Follow the procedures in "Before You Begin."
2. Release and remove the front panel.
3. Remove the middle and bottom front-panel inserts by pushing the back of the inserts. If a secondary CD drive is installed, then you will only remove the
bottom panel insert.

1
side hinges
2
front panel
NOTICE: To connect a network cable, first plug the cable into the network wall jack and then plug it into the computer.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before opening the cover.
