1. Coin-cell battery 2. Optional video connector (HDMI/VGA/DP port)
3. Optional I/O cable connector (USB 3.2 Gen 1 Type-C port
with DisplayPort Alt mode)
4. Memory module slots
5. WLAN card connector 6. M.2 220 solid-state drive connector
The following images indicate the location of the system board and provide a visual representation of the installation procedure.
