Dell OptiPlex 380 - Page 44

Express x1):
Mini-tower
one

Desktop
one (with combo riser installed)

Small form factor
none
one
Drives
Externally accessible:

5.25-inch drive bays
Mini-tower — two
Desktop — one
Small form factor — one (slim line)
Internally accessible:

3.5-inch drive bays
Mini-tower — two
Desktop — one
Small form factor — one
ExternalConnectors
Audio:

back panel
two connectors for line-out and line-in/microphone
front panel
two connectors for microphone and headphone
Network adapter
one RJ45 connector
Serial
one 9-pin connector; 16550C compatible
Parallel
one 25-pin connector
USB:

front panel
two
back panel
six
Video
15-pin VGA connector
28-pin DVI-I connector
NOTE: Available video connectors may vary based on the graphics
card selected.
SystemBoardConnectors
PCI 2.3:

connectors
120-pin connector
data width (maximum)
32 bits
PCI Express x16:

connectors
164-pin connector
data width (maximum)
16 PCI-Express lanes
Serial ATA
Mini-tower — three 7-pin connectors
Desktop — three 7-pin connectors
Small form factor — two 7-pin connectors
Memory
two 240-pin connectors
Processor fan
one 5-pin connector
System fan
one 5-pin connector
Front panel control/front panel audio
one 40-pin connector
Processor
one LGA775 connector
Power 12V
one 4-pin connector
Power
one 24-pin connector
Power
Mini-Tower:
Wattage
Maximum heat
dissipation
Voltage
Non-EPA
255 W
1338 BTU/hr
115/230VAC,50/60Hz,6.5/3.5A
EPA
255 W
1023 BTU/hr
100-240VAC,50/60Hz,1.8/3.6A
Desktop:



Non-EPA
235 W
1233 BTU/hr
115/230VAC,50/60Hz,6.5/3.5A
EPA
255 W
1023 BTU/hr
100-240VAC,50/60Hz,2.0/4.0A
Small Form Factor:



Non-EPA
235 W
1233 BTU/hr
115/230VAC,50/60Hz,6.5/3.5A
EPA
235 W
943 BTU/hr
100-240VAC,50/60Hz,1.8/3.5A
Coin-cell battery
3V CR2032 lithium coin cell

NOTE: Heatdissipationiscalculatedbyusingthepowersupplywattagerating.
NOTE: See the safety information that shipped with your computer for important voltage–setting information.
