Dell OptiPlex 7000 Tower - Page 73

Steps
1. Disconnect the power-button cable from the connector on the system board.
2. Press the release tabs on the power-button head and slide the power-button cable out from the front-side chassis of the
computer.
3. Pull the power-button cable out from the computer.
Removing and installing components
73
